XFusion 1288H V6 1U Server | Dual Intel Xeon Ice Lake | 32 DDR4 | 12x 2.5" Hot-Swap | PCIe 4.0 | High-Density Computing

Name: XFusion 1288H V6 1U Server Dual Intel Xeon Ice Lake 32 DDR4 12x 25quot HotSwap PCIe 40 HighDensity Computing
Brand: intel
Price: 1 USD

Quality XFusion 1288H V6 1U Server | Dual Intel Xeon Ice Lake | 32 DDR4 | 12x 2.5" Hot-Swap | PCIe 4.0 | High-Density Computing for sale

private mold : Yes

products status : Stock

type : Rack

processor main frequency : 1.9GHz-3.9GHz

processor type : Intel Xeon

Brand Name : intel

Place of Origin : Beijing, China

MOQ : 1 piece

Price : $1,200-2,500 / piece

Contact Now

Product Description

Model	FusionServer 1288H V6
Form Factor	1U rack server
Processors	One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), thermal design power (TDP) up to 270 W
Chipset	Intel C621A
Memory	32 DDR4 DIMMs, up to 3200 MT/s; 16 Optane™ PMem 200 series, up to 3200 MT/s
Local Storage	Supports various drive configurations and hot swappable: • 8 to 12 x 2.5-inch SAS/SATA/SSD drives • 10 x 2.5-inch drives (6–10 NVMe SSDs and 0–4 SAS/SATA drives, with a total number of 10 or less) • 10 x 2.5-inch drives (2–4 NVMe SSDs and 6–8 SAS/SATA drives, with a total number of 10 or less) • 4 x 3.5-inch SAS/SATA/SSD drives Supports flash storage: • Dual M.2 SSDs
RAID Support	Supports RAID 0, 1, 10, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration.
Network	Provides expansion capability of multiple types of networks. Provides the OCP 3.0 network adapter. The two FlexIO card slots support two OCP 3.0 network adapter respectively, which can be configured as required. Supports the hot swap function.
PCIe Expansion	Provides six PCIe slots, including one PCIe slot dedicated for RAID controller card, two FlexIO card slots dedicated for OCP 3.0 network adapters, and three PCIe 4.0 slots for standard PCIe cards.
Fan Modules	Seven hot-swappable counter-rotating fan modules in N+1 redundancy mode
Power Supply	Two hot-swappable PSUs in 1+1 redundancy mode. Supported options include: • 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC) • 1500 W AC Platinum PSUs • 1000 W (input: 100 V to 127 V AC) • 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC) • 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC) • 1200 W –48 V to –60 V DC PSUs (input: –38.4 V to –72 V DC) • 2000 W AC Platinum PSUs • 1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC) • 2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC)
OS	Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle Linux, Ubuntu, Debian, openEuler, etc .
Dimensions (H x W x D)	Chassis with 3.5-inch drives: 43.5 mm x 447 mm x 790 mm (1.71 in. x 17.60 in. x 31.10 in.) Chassis with 2.5-inch drives: 43.5 mm x 447 mm x 790 mm (1.71 in. x 17.60 in. x 31.10 in.)

XFusion 1288H V6 1U Server | Dual Intel Xeon Ice Lake | 32 DDR4 | 12x 2.5" Hot-Swap | PCIe 4.0 | High-Density Computing

Company Information

Packaging & Shipping

FAQ

Q1: Are you the TRADING COMPANY OrTECHNOLOGYCOMPANY?
A: We're A technology company, which have a team full ofin-house certified technicians and specialists in IT we all have over 20 years’ experience, so we can provide you professional technical service
Q2: Why can you become my long-term partner?
A: We have cooperated with major well-known marand have been granted authorization qualifications.Dell, HPE, HUAWEl, Lenovo, Inspur, etc. And we are alsoAlibaba Verified Gold Supplier, which have A strong and professionally trained pre-sales and after-sales team
Q3: How can you guarantee the quality of the goods ?
A: Well, as we are authorized by the cooperating manufacturer, we only provide original brand-new products . Before delivery, our engineer will do the test for all the products , and make sure they have 100%new appearance, also can 100% work well.
Q4:How about the warranty?
A: All of our goods is 3years warranty
Q5: When l placed orders from you, how about the lead time?
A: most of our goods are in stock, but anyway, we will try our best to ship the goods for you asap and use the fast shipping way to ship the goods
Q6: how we make payment ?which way do you have
A: TT, alibaba,paypal, WU. for these ways , you can use any way you want
