Wholesale X FUSION Server 1288H V5 V6 V7 1U Tower Rack Server with New Xeon CPU 32GB DDR4 Memory HDD in Stock

Model

FusionSever 1288H V6

Processor

1 or 2 × 3rd Gen Intel® Xeon® Scalable Processors

Memory Slots

32 × DDR4 DIMM slots

Power Supply

Two hot-swappable PSUs in 1+1 redundancy mode. Supported options include:
• 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC)
• 1500 W AC Platinum PSUs
• 1000 W (input: 100 V to 127 V AC)
• 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC)
• 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC)
• 1200 W –48 V to –60 V DC PSUs (input: –38.4 V to –72 V DC)
• 2000 W AC Platinum PSUs
• 1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC)
• 2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC)

RAID Support

Supports RAID 0, 1, 10, 5, 50, 6, or 60, optional supercapacitor for cache data power failure protection, RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration.

Network

Provides expansion capability of multiple types of networks.
Provides the OCP 3.0 network adapter. The two FlexIO card slots support two OCP 3.0 network adapter respectively, which can be configured as required.
Supports the hot swap function.

PCIe Expansion

Provides six PCIe slots, including one PCIe slot dedicated for RAID controller card, two FlexIO card slots dedicated for OCP 3.0 network adapters, and three PCIe 4.0 slots for standard PCIe cards.

Chipset

Intel C621A

Drive Bays

Supports up to 10 × NVMe SSDs

Cooling

7 × hot-swappable counter-rotating fans (N+1 redundancy supported)

Dimensions (H×W×D)

Chassis with 3.5-inch drives: 43.5 mm x 447 mm x 790 mm (1.71 in. x 17.60 in. x 31.10 in.)
Chassis with 2.5-inch drives: 43.5 mm x 447 mm x 790 mm (1.71 in. x 17.60 in. x 31.10 in.)
