Product Description
FusionServer 2488 V5 is a 2U 4-socket rack server. It offers an ideal choice for compute-intensive applications,
such as virtualization, HPC, database, and SAP HANA. One FusionServer 2488 V5 server reduces OPEX by about
32% compared with 2 traditional 2U, 2S rack servers. The FusionServer 2488 V5 supports 4 Intel® Xeon® Scalable
processors in a 2U space, up to 32 DDR4 DIMMs , and up to 25 x 2.5-inch hard drives for local storage (configurable
with 8 NVMe SSDs). It also incorporates patented technologies such as Dynamic Energy Management Technology
(DEMT) and Fault Diagnosis & Management (FDM), and integrates FusionDirector software for entire-lifecycle
management,helping customers drive down OPEX and improve ROI. * Source: Test results from Global Computing
Innovation OpenLab, Q2 2017.
| Model | FusionServer 2488 V5 |
| Processors | 2 or 4 1st Generation Intel® Xeon® Scalable processors (5100/6100/8100 series), up to 205 W 2 or 4 2nd Generation Intel® Xeon® Scalable processors (5200/6200/8200 series), up to 205 W |
| Memory | 32 DDR4 DIMM slots, 2933 MT/s; up to 8 Intel® Optane™ PMem modules (100 series), 2666 MT/s |
| raid | RAID 0, 1, 10, 1E, 5, 50, 6, or 60 Configured with a supercapacitor for cache power-off protection Supports RAID level migration, drive roaming |
| Hard drive disk | Supports hot-swappable hard drives with the following configuration options: 8 x 2.5-inch SAS/SATA HDDs on the front 25 x 2.5-inch SAS/SATA HDDs on the front 8 x 2.5-inch NVMe SSDs and 16 x 2.5-inch SAS/SATA HDDs on the front Flash storage: 2 x M.2 SSDs |
| Power supply | 2 hot-swappable PSUs, with support for 1+1 redundancy. The following PSUs are supported: 2,000W AC Platinum PSUs 1,500W AC Platinum PSUs 900W AC Platinum PSUs 1,200W DC PSUs |
| PCIe Expansion | Up to 9 PCIe 3.0 slots |
| Certifications | CE, UL, FCC, CCC, and RoHS |
| LOM Network Ports | 2 x GE + 2 x 10 GE ports |
| Fan Modules | 4 hot-swappable fan modules, providing protection against single-fan failures |
| Form Factor | 2U rack server |
| Dimensions | 8.6*44.7*74.8cm |
Company Information
packing
Vesting Instrument
Contact US
FAQ
Q1: Are you the TRADING COMPANY Or TECHNOLOGY COMPANY?
A: We're A technology company, which have a team full ofin-house certified technicians and specialists
in IT we all have over 20 years’ experience, so we can provide you professional technical service.
Q2: Why can you become my long-term partner?
A: We have cooperated with major well-known marand have been granted authorization qualifications.
Dell, HPE, HUAWEl, Lenovo, Inspur, etc. And we are alsoAlibaba Verified Gold Supplier, which have A strong
and professionally trained pre-sales and after-sales team.
Q3: How can you guarantee the quality of the goods?
A: Well, as we are authorized by the cooperating manufacturer, we only provide original brand-new products .
Before delivery, our engineer will do the test for all the products , and make sure they have 100%new appearance,
also can 100% work well.
Q4:How about the warranty?
A: All of our goods is 3years warranty.
Q5: When l placed orders from you, how about the lead time?
A: most of our goods are in stock, but anyway, we will try our best to ship the goods for you asap and use the fast
shipping way to ship the goods.
Q6: how we make payment ? which way do you have?
A: TT, alibaba,paypal, WU. for these ways , you can use any way you want.
