Refurished Server 2288H V5 with 24 DDR4 12LFF 900W 2U Rack Sever

Name: Refurished Server 2288H V5 with 24 DDR4 12LFF 900W 2U Rack Sever
Brand: huawei
Price: 1 USD

Quality Refurished Server 2288H V5 with 24 DDR4 12LFF 900W 2U Rack Sever for sale

private mold : Yes

products status : Stock

type : Rack

processor main frequency : 2.1GHZ

processor type : 1st Generation Intel Xeon Scalable processors

Brand Name : huawei

Place of Origin : Beijing, China

Product name : FusionServer 2288H V5

Processor : 1st Generation Intel Xeon Scalable processors

Memory : 24 DDR4 DIMM slots, 2933 MT/s

Hard Drive : 12/16/20 x 3.5-inch SAS/SATA hard drives

RAID Controller : RAID 0, 1, 10, 1E, 5, 50, 6, or 60

Power Supply : 550W/900W/1200W/1500W

Network ports : 2 x 10GE + 2 x GE

Form Factor : 2U rack server

Dimensions : 8.6*44.7*74.8cm

Fan modules : 4 hot-swappable counter-rotating fan modules

MOQ : 1 piece

Price : $1,500-2,800 / piece

Contact Now

Product Description

Huawei FusionServer 2288H V5 is a 2U 2-socket rack server for Internet, Internet data center (IDC), cloud computing, enterprise,

and telecom service applications. Marked H22H-05 on the nameplate, the 2288H V5 is ideal for IT core services, cloud computing

virtualization, high-performance computing, distributed storage, big data processing, enterprise or telecom service applications,

and other complex workloads. It combines low power consumption with high scalability and reliability, and ease of deployment

and management.

Model	FusionServer 2288H V5
Processors	1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205 W 1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205 W
Memory	24 DDR4 DIMM slots, 2933 MT/s; up to 12 DCPMMs, 2666 MT/s
raid	RAID 0, 1, 10, 1E, 5, 50, 6, or 60 • Configured with a supercapacitor for cache power-off protection • Supports RAID level migration, drive roaming, self-diagnosis, and web-based remote configuration
Hard drive disk	Supports hot-swappable hard drives with the following configuration options: • 8 x 2.5-inch SAS/SATA hard drives • 12/16/20 x 3.5-inch SAS/SATA hard drives • 4, 8, 12, 24, or 28 NVMe SSDs • 31 x 2.5-inch SAS/SATA hard drives Flash storage: • 2 M.2 SSDs
Power supply	2 hot-swappable PSUs with support for 1+1 redundancy and the following configuration options: • 550 W AC Platinum PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC) • 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC) • 1500 W AC Platinum PSUs 1000 W (input: 100 V to 127 V AC) 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC) • 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC) • 1200 W -48 V to -60 V DC PSUs (input: -38.4 V to -72 V DC)
Dimensions	*8.644.774.8cm*
Fan modules	4 hot-swappable counter-rotating fan modules with support for N+1 redundancy
Network ports	LOM: 2 x 10GE + 2 x GE ports Flexible NIC: 2 x GE, 4 x GE, 2 x 10GE, 2 x 25GE, or 1/2 x 56G FDR IB ports
