| Server Model | FusionServer 2288 V7 |
| Form Factor | 2U rack server |
| | 1/2 fourth-generation Intel® Xeon® Scalable Processor (Sapphire Rapids), single processor supports up to 225W |
|
Local Storage
| Support a variety of different hard disk configurations, hard disk supports hot swap: • Can be configured with 8-31 2.5-inch
SAS/SATA/SSD hard drives • Can be configured with 10-14 3.5-inch SAS/SATA hard drives
• Can be configured with 4 NVMe SSD disks
• Maximum support for 31 2.5-inch hard drives
Support Flash storage:
• Dual M.2 SSDs |
|
RAID support
| Optional support RAID0, 1, 10, 1E, 5, 50, 6, 60, etc., support Cache super capacitor protection, provide RAID level migration,disk
roaming, self-diagnosis, Web remote setting and other functions |
| The internet | Support multiple network expansion capabilitiesSupport OCP 3.0 network card - 1 FLEX IO card slot supports 1 OCP 3.0 network card,
support on-demand configuration |
|
PCIe Expansion
| Up to 8 PCIe expansion slots1 dedicated FLEX IO expansion slot for OCP3.0, 1 dedicated expansion slot for RAID card, 6 standard
PCIe expansion slots |
| Chip Set | Emmitsburg PCH |
| GPU accelerator card | Support four 75W half-height half-length GPU accelerator cards |
| Operating Systems | Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu, Debian,
etc. |
| Security Features | Power-on password, administrator password, TPM 2.0, security panel, secure boot, and cover opening detection. |
| Fan Modules | 4 hot-swappable counter-rotating fans, supporting N+1 redundancy |
| Operating Temperature | 5°C to 45°C (41°F to 113°F) (ASHRAE Classes A1 to A4 compliant) |
| Certifications | CE, UL, CCC, FCC, VCCI, RoHS, etc |
| Installation Kit | L-shaped guide rails, adjustable guide rails, and holding rails. |
| size | 3.5-inch HDD chassis dimensions: 86.1 mm× 447 mm× 798 mm
2.5-inch HDD chassis dimensions: 86.1 mm× 447 mm× 798 mm |
|
Power Supply Units
| It can be configured with 2 redundant hot-swappable power supplies, supporting 1+1 redundancy, and the optional specifications are
as follows: • 900W AC platinum/titanium power supply (input: 100 V AC ~ 240 V AC or 192V DC ~ 288V DC)
• 1500W AC Platinum Power Supply
1000W (input: 100V AC ~ 127V AC)
1500W (input: 200V AC~240V AC or 192V DC~288V DC)
• 1500W 380V high voltage DC power supply (input: 260V DC~400V DC)
• 1200W -48V~-60V DC power supply (input: -38.4V DC~-72V DC)
• 3000W AC titanium power supply
2500W (input: 200V AC ~ 220V AC)
2900W (input: 220V AC ~ 230V AC)
3000W (input: 230V AC ~ 240V AC)
• 2000W AC platinum/titanium power supply
1800W (input: 200V AC~220V AC or 192V DC~200V DC)
2000W (input: 220V AC ~ 240V AC or 200V DC ~ 288V DC) |
