private mold : Yes
products status : Stock
type : Rack
processor main frequency : 2.3GHZ
processor type : 2
Brand Name : HP
Place of Origin : Beijing, China
Product Name : Server Motherboard
Form Factor : 2U Rack Serverr
Processor speed : The upper limit is 3.1 GHz, depending on the processor model
Hard Drive : 2.5/3.5 SAS/SATA/SSD/NVME
Memory slots : 32x DDR5 Memory Slots
Storage controller : HPE MR408i-o Gen11 x8 channel 4 GB high-speed cache
The number of available processor cores : 16 to 60 cores, depending on the processor model
RAID Controller : RAID 0/1/5/6/10/50/60
Power Supply : 800W 1000W 1600W
Package : 87.5 *448*727mm
MOQ : 1 piece
Price : $280-3,500 / piece


| processor | Support 2 4th generation Intel ® Xeon ® scalable processors, single up to 60 cores, maximum power 350W |
| memory | Supports up to 32 DDR5 DIMMs with a maximum rate of 4800MT/s and a maximum memory capacity of 8TB |
| Permanent memory | Intel ® Odo ® durable memory support |
| Memory controller | Optional Tri-mode (NVMe/SAS/SATA) HPE Smart Array controller, maximum cache 8GB Supports SATA RAID 0, 1, 10, and 5 Supports Intel VROC and HPE intelligent storage SR100i Optionally, two M.2 solid state drives (NS204i-u) are provided as raid1 hot-swappable OS boot device, and a MicroSD card is optional |
| storage | Supports up to 30 2.5-inch SATA/SAS hard drives (24 front + 6 rear expansion) Supports up to 16 3.5-inch SATA/SAS hard drives (12 front + 4 rear expansion) Supports up to 36 EDSFF 3.S 1T NVMe hard drives or 18 EDSFF 3.S 2T NVMe hard drives Support for NVMe U.2, U.3, EDSFF, and M.2 SSDS |
| network | Optional Network adapters based on standard PCIe slots The OCP 3.0 NIC is optional |
| Expansion slot | Three PCIe 5.0 slots are standard and up to eight PCIe 5.0 slots are supported Supports two x16 OCP 3.0 slots |
| interface | Optional front display port, optional rear serial port, standard with rear VGA 4 USB 3.0 ports (1 front, 2 rear, 1 built-in), 3 USB 2.0 ports (2 optional, 1 built-in) |
| GPU support | Supports up to eight single-width Gpus or three double-width Gpus |
| Optical drive | Supports external CD-ROM drive |
| management | iLO Standard Edition is standard. iLO Advanced Edition and OneView Advanced Edition are optional Supports HPE iLO 6, SUM, and RESTful interface tools Support for mobile application software APP |
| Power supply and heat dissipation | Optional up to 1600W 1+1 hot swap redundant power supply, support up to 96% titanium; Supports hot-swappable redundant fans |
| Operating temperature | 5℃ to 45℃ |
| Case size | 2U standard chassis 87.5mm(H) x 448mm(W) x 727mm(D) (2.5-inch hard disk models) 87.5mm(H) x 448mm(W) x 742.5mm(D) (Models with 3.5-inch hard disks) |
| warranty | Channel sales Pre-configured (BTO) models 3 years 5 x 9 next working day response Project sales per order configuration (CTO) models 3 years 7 x 24 x 4 hours service |









| Our Advantage: | |||||||||||||||||||
| 1. Fast lead time: We have produce in stock, we can fast delivery. | |||||||||||||||||||
| 2. Long warranty period: Our products have 3 years or 5 years warranty. | |||||||||||||||||||
| 3. Fast and effective service: Our team are 24 hours service for you online by Email / Mobile / Skype / Whats app. | |||||||||||||||||||
| 4. Professional technical team:
|
|
|
