| Processor | Supports up to 2 Intel Xeon 3rd Gen Scalable family processors or Montage Tytek ® processor series, with up to 40 cores and a maximum power of 270W®® |
| Chipset | ® Intel C621A |
| memory | It supports up to 32 DDR4 memory slots, supports up to 3200MT/s, supports RDIMM or LRDIMM, and has a maximum capacity of 6TB for a single processor Supports up to 16 Intel ® Optane ® persistent memory PMem 200 series |
| Storage controllers | On-board array controller is standard, supporting SATA RAID 0/1/10/5 Standard PCIe slot-based HBA cards and array cards are available |
| FBWC | Optional support for up to 8GB of cache with support for supercapacitor protection |
| storage | Supports up to 41 HDDs (37 x 2.5-inch HDDs, 4 x 3.5-inch HDDs) Supports up to 20 x 3.5-inch HDDs (12 front, 4 internal expansion, 4 rear expansion); Supports up to 37 x 2.5-inch HDDs (25 front, 8 internal expansion, 4 rear expansion); Support SAS/SATA HDD/SSD hard disk; Supports front/internal NVMe hard drives, supporting up to 32 NVMe hard drive slots1, which supports PCIe NVMe storage accelerator cards Supports SATA and PCIe M.2 options, supports 2 Micro SD card kits |
| Internet | One 1Gbps dedicated management network port on board Up to two OCP 3.0 NICs can be selected, and 4×1GE electrical ports, 2×10GE electrical/optical ports, or 2×25GE optical ports can be expanded Optional standard PCIe slot-based network adapter for 1/10/25/40/100/200 GE network cards, IB cards |
| Expansion slots | Supports up to 14 PCIe 4.0 standard slots and 1 OCP 3.0 slot (PCIe 4.0 rate) |
| interface | It comes standard with 1 front VGA, 1 rear VGA and 1 serial port, 6 USB 3.0 (2 front, 2 rear, 2 built-in), and 1 front dedicated management interface |
| GPU support | Supports up to 4 double-wide GPU cards or 14 single-wide GPU cards |
| Drive | External optical drives are supported |
| manage | HDM agentless management tool (with independent management port) and H3C UniSystem management software, support LCD touchable intelligent management module, support 64M local video memory Optional U-Center data center management platform |
| security | Support secure chassis, TCM/TPM security module, two-factor authentication |
| Power and cooling | Platinum 550W / 800W / 850W / 1200W / 1300W / 1600W /2000W 1+1 redundant power supply is available, and titanium power supply is optional Optional 800W negative 48V/336V DC power module, support 1+1 redundancy Hot-swappable redundant fans are supported |
| authentication | Support CCC, SEPA and other certifications |
| Operating temperature | 5°C - 45°C (Operating temperature support is affected by different configurations, please refer to the detailed product technical documentation for details) |
| Form factor/chassis size | 2U chassis 87.5mm(H)*445.4mm(W)*748mm(D) (without security panel) 87.5mm(H)*445.4mm(W)*776mm(D) (including security panel) |
| Warranty | 3 years 5×9, Next Business Day Response (NBD) |
